The Express 400 DoubleFacer is a high-speed machine offering flexibility in configuration, installation, machine features, and speeds up to 1500 ft/min.
This machine utilizes Fosber’s advanced Syncro automatic control with cast iron hot plates, automatic width adjustment, and recipe-based control. Hot-plate steam pressures are variable from 7-220 psi and can be 9 to 20 plate configurations.
The Express 400 is a cost-effective machine that provides the most options for your current needs and allows the most flexibility for future modifications or changes to your corrugator.
- Width: 98″ or 110
- Speed: 1500 ft/min
- Allen-Bradley Electronics
- Intelligent Guard Monitoring
- Cast Iron Hot Plates
- 3 or 4 Zones for Steam and Shoe Pressure Configuration
- Full Width Shoes
- Ability to Raise Longitudinal Rails
- Hydraulic “Cammed” Shoe System
- Easy Thread-Up Design
- Belt Cleaner (Optional)
- Jet Assist (Optional)
